The two-valued Slerp can be extended to interpolate among many unit quaternions, but the extension loses the fixed execution-time of the Slerp algorithm. For example, the de Casteljau algorithm may be used to split a curve in affine space this does not work on a sphere. Since the sphere is not an affine space, familiar properties of affine constructions may fail, though the constructed curves may otherwise be entirely satisfactory. Quaternion Slerps are commonly used to construct smooth animation curves by mimicking affine constructions like the de Casteljau algorithm for Bézier curves. Slerp curves not extending through a point fail to transform into lines in that point's tangent space. In the tangent space at any point on a quaternion Slerp curve, the inverse of the exponential map transforms the curve into a line segment. The initial tangent vector is parallel transported to each tangent along the curve thus the curve is, indeed, a geodesic. The derivative of Slerp( q 0, q 1 t) with respect to t, assuming the ends are fixed, is log( q 1 q 0 −1) times the function value, where the quaternion natural logarithm in this case yields half the 3D angular velocity vector. If you want to rotate the object to a specific angle use: float degrees 90 Vector3 to new Vector3 (degrees, 0, 0) transform. Slerp ( p 0, p 1 t ) = sin sin Ω p 0 + sin sin Ω p 1.
Compute Ω as the angle subtended by the arc, so that cos Ω = p 0 ∙ p 1, the n-dimensional dot product of the unit vectors from the origin to the ends.
Let p 0 and p 1 be the first and last points of the arc, and let t be the parameter, 0 ≤ t ≤ 1. This formula, a symmetric weighted sum credited to Glenn Davis, is based on the fact that any point on the curve must be a linear combination of the ends. Slerp has a geometric formula independent of quaternions, and independent of the dimension of the space in which the arc is embedded. It refers to constant-speed motion along a unit-radius great circle arc, given the ends and an interpolation parameter between 0 and 1. In computer graphics, Slerp is shorthand for spherical linear interpolation, introduced by Ken Shoemake in the context of quaternion interpolation for the purpose of animating 3D rotation. Also thanks to Josh for sending a number of improvements.
This is based on code sent to me by Anthony(Prospero). ( April 2021) ( Learn how and when to remove this template message) The following code generates a quaternion between two given quaternions in proportion to the variable t, if t0 then qmqa, if t1 then qmqb, if t is between them then qm will interpolate between them. Please help to improve this article by introducing more precise citations. This article includes a list of general references, but it lacks sufficient corresponding inline citations.
